VFE-P711AD OLED Viewfinder

VFE-P711AD features a high-performance 7-inch OLED panel that delivers exceptional brightness, high contrast, and fast response, ideal for live sports broadcast and HFR (High Frame Rate). UniMenu further enhances operability by unifying camera and viewfinder controls into a single, intuitive menu accessible from either device.

VFE-P711AD is a new studio viewfinder with digital and analog connectivity, designed for use with cameras such as the UNICAM XE series and UNICAM HD series. This new viewfinder is available in 5 different pre-configured packages to meet any budget and production requirement:

Pack-S: the standard attachment kit with basic operability.

Pack RF: the standard attachment kit with basic operability and special bracket to be mounted on the UNICAM XE wireless camera model (UHK-X700RF/ -X600RF and HDK-X500RF)

Pack A: the advanced attachment kit with wider adjustment range (for the portable camera UHK-X700/-X600 and HDK-X500).

Pack B: the advanced attachment kit with wider adjustment range (for the system expander SE-U430).

Pack C: the advanced attachment kit with wider adjustment range (for the studio heads UHK-X750/-X650).

Key Features:

• High Performance 7-inch OLED Panel
• The OLED panel’s high brightness and excellent contrast ratio ensure clear visibility even under strong ambient lighting. Its fast response speed enables more precise focusing, especially in High Frame Rate shooting.
• Digital and Analog interface: The VFE-P711AD adopts the end-to-end digital video processing of the UNICAM XE series. Its clear image quality makes accurate focusing easy.Also included is an analog interface compatible with conventional UNICAM HD cameras via an optional VF cable.
• Interactive Camera - VF Control (UniMenu): UniMenu delivers smarter control through bidirectional camera and viewfinder integration. Operators can access and adjust the same menu from either the camera head or the viewfinder, simplifying setup and on-site operation.
• Waveform Monitor/Vectorscope: The VFE-P711AD viewfinder incorporates a variety of test-related tools including a waveform monitor, vectorscope and audio level meter.
• External Inputs: supporting 3G/HD-SDI input, the VFE-P711AD can be also used as a field monitor.
• Various Display Marker
• Software update via USB-C
